Jade Built-In Refrigerators - INSTALLATION GUIDE - CUTOUT DIMENSION SPECIFICATIONS

Exterior Dimensions 48" STAINLESS STEEL 48" OVERLAY 48" FRAMED 42" STAINLESS STEEL 42" OVERLAY 42" FRAMED
Model Numbers RJRS4880 RJRS4881 RJRS4882 RJRS4280 RJRS4281 RJRS4282
RJRS4870 RJRS4871 RJRS4872 RJRS4270 RJRS4271 RJRS4272
in. cm in. cm in. cm in. cm in. cm in. cm
A. Cutout Height 83
3
⁄4 212.7 83
3
⁄4 212.7 83
3
⁄4 212.7 83
3
⁄4 212.7 83
3
⁄4 212.7 83
3
⁄4 212.7
B. Cutout Width 47
1
⁄2 120.7 47
1
⁄2 120.7 47
1
⁄2 120.7 41
1
⁄2 105.4 41
1
⁄2 105.4 41
1
⁄2 105.4
C. Cutout Depth 24 61.0 24 61.0 24 61.0 24 61.0 24 61.0 24 61.0
D. Height To Top Of Cabinet
†
83
1
⁄16 210.9 83
1
⁄16 210.9 83
1
⁄16 210.9 83
1
⁄16 210.9 83
1
⁄16 210.9 83
1
⁄16 210.9
E. Height To Top Of Grille 83
3
⁄8 211.8 83
3
⁄8 211.8 83
3
⁄8 211.8 83
3
⁄8 211.8 83
3
⁄8 211.8 83
3
⁄8 211.8
F. Width (Cabinet) 47
1
⁄4 120.0 47
1
⁄4 120.0 47
1
⁄4 120.0 41
1
⁄4 104.8 41
1
⁄4 104.8 41
1
⁄4 104.8
G. Width (Doors Closed) 48
1
⁄16 122.1 48
1
⁄16 122.1 48
1
⁄16 122.1 42
1
⁄16 106.8 42
1
⁄16 106.8 42
1
⁄16 106.8
H. Depth Excl. Handles (Closed) 25
1
⁄4 64.1 25
1
⁄4 64.1 25
1
⁄4 64.1 25
1
⁄4 64.1 25
1
⁄4 64.1 25
1
⁄4 64.1
I. Depth Incl. Handles (Closed) 26
5
⁄8 67.6 NA 26
3
⁄8 67.0
††
26
5
⁄8 67.2 NA 26
3
⁄8 67.0
††
J. Depth (Fresh Food Door 52
9
⁄16 133.5 52
9
⁄16 133.5 52
9
⁄16 133.5 48
3
⁄4 123.8 48
3
⁄4 123.8 48
3
⁄4 123.8
Open 90°)
K. Width (Doors Open 90°, 50
3
⁄4 128.9 NA 50
1
⁄4 127.6
†††
44
3
⁄4 113.7 NA 44
1
⁄4 112.4
†††
Including Handles) 51
7
⁄8 131.8 45
7
⁄8 116.5
†
1
1
⁄4" (3.2 cm) vertical adjustment for leveling and height adjustments.
††
Add 1" (2.5 cm) to depth (I) for extended handle kit, if used, on framed model.
†††
Add 2" (5.1 cm) to width (K) for extended handle kit, if used, on framed model.
INSTALLATION GUIDE – CUTOUT DIMENSION SPECIFICATIONS
A
B
D
E
F
I
H
G
J
K
C
TOP VIEW
Important: Because of continuing product improvements, Jade reserves the right to change specifications without notice. Dimensional specifications are provided for
planning purposes only. For complete details see installation instructions packed with product before selecting cabinetry, making cutouts or beginning installation.
