partS liSt technical data
Voltage 220-240 V~, 50 Hz
Engine speed 55 rpm
Engine output 180 W
Remote control operating distance 30 m (Frequency: 433.92 mHz)
Remote control mode Single button
Output shaft height 48.5 mm
Max. gate weight 600 kg
Output torque 16 Nm
Limit switch Spring limit switch
Noise development ≤ 56 dB
Duty cycle Max. 15 minutes (followed by 5 minutes of
rest)
Remote control settings 25
Environmental temperature -20°C ~ +50°C
Gate speed 13 m/min
inStallation
The sliding gate operator
is suitable for gates with a
weight of up to 600 kg and
a width of up to 12 m. This
gate operator works with a
rail which is driven by a gear.
The gate operator must be
installed on the inside of the
gate (see construction Fig.
1).
Fig. 1
Gate
Gate operator
Input power
Rail
Switch*
Wall
*Single-/Three-button switch
(not included in the delivery)
