RAC Plus I User’s Manual
2-10
Installing the Magnetic Distance Sensor
Note: These instructions are for installing a RAC Plus I with a Magnetic
Distance Sensor. If you are installing a different sensor, skip this section.
For the installation you will need the Magnetic Sensor Kit shown below.
A – Magnets
B – Epoxy
C – Zip Ties
D – Mounting Bracket
E – Hardware Kit
F – Magnetic Sensor
G – Extension Cable
and the Vehicle Installation Kit shown below.
H – Terminal Block
I – Power Cable
J – Ground Cable
K – DMI Connector Cable
L – Velcro
M – Zip Ties
F
G
D
B
A
E
C
Fig. 2-10
Fig. 2-11
H
I J
K
L
M
