Safety Information
This radio control model is not a toy!
Suitable for persons over 14 years!
Note: Not suitable for children under 36 months.
Risk of suffocation.
Contains small parts which can be swallowed.
WARNING!
• Readtheinstructionscarefullybeforeusingthemodel.
Keep the instructions and packing after reading it.
Operating Safety Instructions
• Thisproductisnotintendedforusebyindividuals(including
children) with reduced physical, sensory or mental capabilities
or lack of experience and / or knowledge, unless they are
supervised by a person responsible for their safety and is able
to give instructions about how the product should be used.
Children should be supervised to ensure that they do not play
with the porduct.
• Readcarefullyandfullyunderstandtheinstructionsbefore
commencing assembly.
• Takeenoughsafetyprecautionspriortooperatingthismodel.
You are responsible for this model’s assembly and safe
operation!
• Whenassemblingthiskit,toolsincludingknivesareused.
 Extracareshouldbetakentoaviodpersonalinjury.
• Readandfollowtheinstructionssuppliedwithpaintsand/or
 Qcement,ifused(notincluded).
• Alwayskeepthisinstructionmanualreadyathandforquick
reference, even after completing the assembly.
• Keephands,hairandlooseclothingawayfromrotatingand
heated parts.
• Neverallowanythingtocomeintocontactwithrotatingparts.
• Themodelcanonlybeowningoodweather.Donotyin
wind, rain or thunder storms.
• Findaplacetoywhichcomplieswithanylaws,andisfree
from obstacles.
• Makesurethatnooneelseisusingthesamefrequencyin
 yourrunningarea.Usingthesamefrequencyatthesame
time can cause seriou accidents, whether it’s driving.
• Themodelshouldnotbechangedinanyway,doingsowill
invalidate the guarantee.
• Donotexposethemodelorbatteriestodirectsunlight,always
keep them in the shade.
General Safety Instructions
• Assemblethis
kitonlyinplacesoutofchildren’sreach!Thekit
contains small parts which may cause choking if swallowed,
keep away from small children.
• NEVERyyourmodeloverpeopleandneveroperatethe
model in way which may endanger people, small children or
animals.
• Neveroperatethemodelonrainoroverdampsurfaces,this
may damage the electronics. If R/C unit, motor, or battery get
wet, clean and dry thoroughly in a dry shaded area.
• Ifthismodelistherstradiocontrolledmodelwhichyouare
attempting to build or run, you should secure the assistance of
an experienced model pilot. Your local dealer will be able to
assist you in locating your local model model sport club or
experienced pilots in your area.
• Inspectthemodelbeforeandaftereverydrivefordamage
and loosing screws and plug connections. The operator is
 responsibleforanydamagecausedbytheoperationofying
models.
• Rememberthatyourmodelismadefromsuchmaterialsas
 plasticandrubberandassuchisinammable.Keepitaway
 fromanyopename,orhightemperatures.
• Whenoperatingthemodel,switchonthetransmitterrstand
then the model, switch off in the reverse order.
• Alwaysensurethatthethrottlestickisinthelowposition
before you switch on.
Important Information for use of batteries and battery packs
• Adheretothespecicationofhowthebatteriesshouldbe
taken out or placed into the product.
• Donotrechargedisposablebatteries!
• Rechargeablebatteriesshouldbetakenoutofthemodel
 beforecharging(ifapplicable)!
• Onlychargerechargeablebatteriesunderadultsupervision!
• Differenttypesofbatteriesornewandusedbatteriesshould
not be used together!
• Adheretocorrectpolarity!
• Removespentbatteriesfromthedevice!
• Donotshortcircuitconnectionterminals!
• Theincludedbattery
isnotcharged!Chargebeforeuse!
• Donotchargethebatterypackimmediatelyafteruse!Ifthe
battery pack becomes warm during use, leave it to cool down
before charging!
• Avoidshortcircuits!Thiscouldintheworstcasecauseres
and in any case it will reduce the battery life.
• Onlyrechargebatterypackswithsamecapacityand
 specicationsasthesuppliedbatterypackifyouintendtouse
the supplied charger.
• Keepbatteriesawayfromsmallchildren!
Information on how to charge the battery pack
• Connectthebatterytothecharger.
• Plugthechargerintothesocket.
• Oncefullycharged,unplugthechargerfromthewallsocket
and disconnect the battery from the charger! The battery is
now ready to use!
