Jands HP12 Technical Manual

Technical Data and Specifications 8-2
Revision 2 - 26 April, 2000 HP SERIES DIMMER TECHNICAL MANUAL
(Australia)
channel channel
HPM CAT38 per
channel (parallel)
PARAMETER HP12-TR HP12-SC HP12-WMTR HP12-WMSC HP6-C
Output Options: Clipsal 415
19 pin Socapex
(normal or series)
10 pin Wieland
Terminal block
Clipsal 415
19 pin Socapex
(normal or series)
10 pin Wieland
Terminal block
Clipsal 415
3x Wieland
GST18 per
channel
2x Wieland
GST18 per
channel
Clipsal 415
3x Wieland
GST18 per
channel
2x Wieland
GST18 per
channel
HPM CAT38
Terminal block
Size (mm): 482 (w) x 133 (h)
x 350 (d)
482 (w) x 133 (h)
x 350 (d)
435 (w) x 485 (h)
x 133 (d)
435 (w) x 485 (h)
x 133 (d)
482 (w) x 133 (h)
x 275 (d)
Weight 20kg 24kg 20kg 24kg 16kg
Ingress Protection IP20 IP20 IP20 IP20 IP20

Jands HP12 Specifications

General

Brand	Jands
Model	HP12
Category	Dimmer
Language	English
