Page #68 background image
Technical Data and Specifications 8-5
Revision 2 - 26 April, 2000 HP SERIES DIMMER TECHNICAL MANUAL
8.2 DMX connector pin-outs
PIN
No
CONNECTION
(DMX IN)
CONNECTION
(LOOP)
1 SHIELD SHIELD
2 IN- OUT-
3 IN+ OUT+
4NC NC
5NC NC
8.3 DMX bank allocations
BANK CHANNELS BANK CHANNELS
1 1 – 12 [6] 23 265 – 276 [270]
2 13 – 24 [18] 24 277 – 288 [282]
3 25 – 36 [30] 25 289 – 300 [294]
4 37 – 48 [42] 26 301 – 312 [306]
5 49 – 60 [54] 27 313 – 324 [318]
6 61 – 72 [66] 28 325 – 336 [330]
7 73 – 84 [78] 29 337 – 348 [342]
8 85 – 96 [90] 30 349 – 360 [354]
9 97 – 108 [102] 31 361 – 372 [366]
10 109 – 120 [114] 32 373 – 384 [378]
11 121 – 132 [126] 33 385 – 396 [390]
12 133 – 144 [138] 34 397 – 408 [402]
13 145 – 156 [150] 35 409 – 420 [414]
14 157 – 168 [162] 36 421 – 432 [426]
15 169 – 180 [174] 37 433 – 444 [438]
16 181 – 192 [186] 38 445 – 456 [450]
17 193 – 204 [198] 39 457 – 468 [462]
18 205 – 216 [210] 40 469 – 480 [474]
19 217 – 228 [222] 41 481 – 492 [486]
20 229 – 240 [234] 42 493 – 504 [498]
21 241 – 252 [246] 43 505 – 512 [510]
22 253 – 264 [258]
