english
27
The handlebar can be set to 7 different positions. Simulta-
neously press the buttons on both sides of the handlebar.
The safety armrest is designed to fit into the slots on the
hammock.
If required it is possible to release one side of the armrest and it
will still be completely articulated by the other side. There are
buttons on the lower part to do this.
6.- USING THE SAFETY ARMREST
To fasten the hood onto the frame of the hammock, slide it
from the top down to the corresponding slots on the central
part. Use the zip on the hood to attach it to the frame.
Follow the same steps in reverse order to take the hood off.
7.- USING THE HOOD
The hammock can be reclined so your baby can travel in the
most comfortable position possible at all times. Pull the lever
on the upper part of the hammock and tilt it to one of the 3
possible positions.
5.- ADJUSTING THE ANGLE OF THE HAMMOCK
8.- ADJUSTING THE HANDLEBAR
WARNING: Position P is only to be used when folding the
pushchair, you must not use this position when your baby
is in the hammock.
WARNING: The child should be kept away from the mobile parts
when the responsible adult is handling these. The appearance
of cutting, compression and pinch points are inevitable during
these operations.
Your pushchair has a safety harness to keep your child safe at
all times. Fit the belt onto the child whenever he is using the
pushchair.
15a. To open the belts, press the button in the middle of the
harness.
15b-c. To fasten it, bring the two side straps together and
then insert them into the harness until they click into place.
15d. Adjust the belts so that they fit the child correctly with
the right tension. To adjust the length of the belts, slide the
buckles up or down. Make sure that the belts are not twisted.
9.- SEAT BELT
15
12-12a
10
11
13-13a
14
