Janome MC12000 User Manual

2
MC 9900
z Push down the carriage arm release lever q.
Extend the carriage arm. Swing out the carriage arm
until it locks in fully extended position.
q
x Remove the setscrew w.
c Slide the carriage in the direction of the arrow.
Remove the setscrew e.
v Remove the Y-carriage cover (upper).
e
Preparation
Remove Y-carriage cover (upper), X-carriage cover
and Embroidery unit cover before replacing to access
carriage parts.
•Removing Y-carriage cover (upper)
w

Janome MC12000 Specifications

General

Type	Computerized Sewing and Embroidery Machine
Needle Positions	91
Display	Color LCD Touchscreen
Thread Tension Control	Automatic
Weight	24.2 lbs
Stitch Width	9 mm
Stitch Length	5 mm
Connectivity	USB
Lighting	LED
Built-in Memory	Yes
USB Port	Yes
Automatic Thread Cutter	Yes
Automatic Needle Threader	Yes
Maximum Sewing Speed	1000 stitches per minute
Embroidery Area	9.1" x 11.8"
