INSTALLATION INSTRUCTIONS
Remove the split nut
Uncoil the manual release cable
and insert the free end of the cable
into the threaded recess
Withdraw (spring loaded) pin and
twist to engage manual release
Fit split nut and tighten
Carefully coil cables together and
secure with a cable tie or similar to
prevent uncoiling or damage during
the installation of the rolling door
STEP 1.
“
Connecting the manual
release cable to the drive
unit”
