(2) Warning Labels
Warning labels are attached at several locations on this instrument. Do not remove,
deface or damage the warning labels. If a warning label peels off the instrument or
becomes illegible, contact your local JASCO distributor (see list on the back cover of
this manual) for a replacement label. Be sure to indicate the part number (P/N) on
the label.
(1) Fuse Warning Label (P/N: 0822-0120A)
Fuse ratings are contained in the maintenance manual.
(2) Electrical Shock Warning Label (P/N: 0822-0125A)
Electrical shock may occur if the instrument is not
properly grounded.
Figure 1 Rear Panel
ONLY WITH FUSE OF THE SPECIFIED
AGAINST RISK OF FIRE, REPLACE
FOR CONTINUED PROTECTION
TYPE AND CURRENT RATINGS.
WARNING
WARNING
MAINS PLUG GROUND PIN
OR GROUND TERMINAL
MUST BE CONNECTED
TO GROUND.
F
U
S
E
P
U
S
H
F
U
S
E
P
U
S
H
T1.6A
T2.5A
100‑120V
220‑240V
FUSE
1
2
3
4
5
6
7
PRESS.ZERO
ADJ.
EVENT
VALVE
GRAD.
LOWPRESS.
8
ACINPUT
GND
FUSE
RS‑232C
R
R
(2) Electrical shock
warning label
(1) Fuse warning label
ONLY WITH FUSE OF THE SPECIFIED
AGAINST RISK OF FIRE, REPLACE
FOR CONTINUED PROTECTION
TYPE AND CURRENT RATINGS.
WARNING
