Jasco Z-Wave Auxiliary Switch User Manual

4-Way Wiring Schematic using two 45710’s and one
45709, 45712 or 45715
SHOCK HAZARD!
Turn OFF the power to the branch circuit for the switch
and lighting xture at the service panel. All wiring
connections must be made with the POWER OFF to
avoid personal injury and/or damage to the switch.
Traveler - Colored (Not Green )
White (Neutral)
Z-Wave
*The
Z-Wave
Black (Line / Hot)
Black
(Load)
Green (Ground)
Traveler - Colored
(Not Green)
Green (Ground)
Z-Wave
45715
does not have
a connection
to neutral
auxiliary
primary
auxiliary
