JFB/JFD 4-17
3. Tighten the straps using the tensioning device provided with the ground
anchors. Use caution to avoid over-tensioning the straps as this may pull the
trailer off the piers. It is recommended that all straps be tightened only
enough to remove the slack. Then, after all THE straps are installed and the
slack removed, tension the straps.
4. The strap tension should be rechecked at frequent intervals until all pier
settlement has stopped.
Fig. 4.7 Frame
tie-down diagram
Inspection Checklist
Once the travel trailer has been set up for long term seasonal camping, the
following items should be checked for proper set up prior to occupancy.
Installation / Placement
Level
Foundation
Tie Downs
Utility connections
Fuel
Water
Electric
Sewage
DETACHABLE HITCH
The hitch is detachable; the instructions to remove and install it are listed below:
SUGGESTED MATERIALS (CUSTOMER SUPPLIED):
Quantity Item Description
4 3 ton jack stands
2 7/8” open end wrench
1 3/4” socket and drive
1 3/8” socket and drive
4 Wood blocks (to chalk tires)
Block tires on both sides of trailer.
1. Unscrew flexible gas hose from main bulkhead on front steel crossmember
and cap both fittings.
2. Remove gas bottles from tongue.
3. Remove electrical wiring and safety break-a-way switch from tongue by
removing 3/8” screws (could be 3 or more).
