SECTION 12
SPECIFICATIONS & GLOSSARY
87
DC FUSE PANEL LAYOUT
Below is a typical wiring layout. Your individual trailer may be different.
# Size Function
1 12.5 amp breaker Bedroom Slideout Motor
2 15 amp fuse Bathroom Lights & Vent
3 15 amp fuse Monitor Panel/Holding Tanks/Water Pump/Water Heater/Kitchen Lights
4 15 amp fuse Refrigerator/Furnace
5 15 amp fuse Bedroom Lights
6 15 amp fuse Propane Detector/TV Outlet
7 15 amp fuse Porch/Entry/Main Living Area Lights
8 15 amp fuse Trunk/Hitch/Living Room Wall/Rear Overhead Cabinet/Rear Ceiling Lights
9 15 amp fuse Main Slideout Lights
10 15 amp fuse Security Lights
11 15 amp fuse Option
12 20 amp breaker Main Slideout Motor
CIRCUIT BREAKERS
The following table provides generic circuit breaker alignment information. Your RV may not be
exactly the same as shown depending on model, floor plan and options.
Main 30-amp Main, incoming power to unit
A 15-amp Microwave
B 15-amp Refrigerator/GFCI (kitchen/bath)
C 20-amp Air conditioner
D 15-amp Utility/converter
E 15-amp Water heater
PROPANE CONSUMPTION CHART
The following chart provides an average propane consumption information.
Appliance Average BTU
Consumption per Hour
Kilojoules/Hour
Water Heater 8,800-10,000 9,280-10,550
Refrigerator 1,200-1,500 1,2701,585
Furnace 20,000-40,000 21,100-42,200
Range Oven 7,100 7,490
Range, Rear Burner 6,500 6,860
Range, Front Burner 9,000 9,490
Outside Grill 10,000 10,550
Outside Stove 13,000 13,730
