Step 9
Locate the bed bow brace for the front
bed (stored under the mat).
Step 10
Attach U-shaped clip to bed bow (between
screw heads).
Step 11
Install the other end of the
bed bow brace into the
bracket between the buttons.
Step 11b
(Slide out-if so
equipped)
Slide the other
end of the bed
bow into the slot
in the roof
bracket.
CAUTION
Some models may have a table next to the bed ends in the stowed or stored
position. Remove the table prior to installing the bed brace. Do not step on, or
put your weight on the table while it is in the stowed position. Doing so may
result in damage to the table and/or personal injury.
