Jayco JAY SERIES User Manual

SECTION 13
SPECIFICATIONS & GLOSSARY
101
DC FUSE PANEL LAYOUT
Below is a typical wiring layout. Your individual trailer may be different.
Operation Location Circuit
Number
Fuse Size Type
Interior Lights, Water
Pump, Radio
In converter 1 15 Blade
Refrigerator In converter 2 15 Blade
Furnace In converter 3 15 Blade
Battery Charge In converter 4 15/20/30* Blade
Battery Prep In line by battery -- 30 Blade
Propane Detecter Behind propane Detector N/A 1 Blade
Fuses
*15-amp with 12-amp converter
*20-amp with 20-amp converter
*30-amp with 30-amp converter
REPLACEMENT LIGHT BULBS
Replacement light bulbs must be of the type, voltage and wattage listed on the lamp fixture. Use of
incorrectly sized bulbs can overload lamp circuits and may create a fire hazard by overheating the
fixture.
Intertior Ceiling, Bunk Lights #921
Intertior Porch Light #912
Intertior Tail Light/Signal #1157
Bulbs
Intertior Clearance #194
PROPANE CONSUMPTION CHART
The following chart provides an average propane consumption information.
Appliance Average BTU
Consumption Per Hour
Kilojoules/Hour
Water Heater 8,800 9,280
Refrigerator 640 672
Furnace 16,000-20,000 16,880-21,100
Stove 6,500-9,000 6,825-9,450
Outside Grill 10,000 10,550
