Jayco JAY SERIES User Manual

SECTION 9
DURA-TEK TENT
72
When you are ready to leave, zip all the
windows closed and roll the privacy drapes
upwards by pressing both buttons on either
side of the black locks and drawing the locks
upwards. Make sure all equipment is properly
stored and will not obstruct the roof when
lowered. If the bed does not close easily,
inspect the bed cushions and tent canvas
from the sides looking for obstructions. Once
the obstruction is located, correct it and try
again.
44
A
fter beds are pulled in, push
tent in all around unit
45
Unfasten
lifter post
covers
and push
them in
46
Make sure all tent and lifter post covers
are inside roof area
47
Finish cranking roof down
48
Fasten all
roof latches
49
Use crank handle
to snug
lifter system
up tight
(do not want
lifter cables hanging
loosely)
DO NOT push the beds or slideout in until
all the velcro has been detached. Push the
bed (and slideout, if so equipped) in
completely before beginning to lower the
roof. Failure to push in the beds and
slideout completely before lowering the
roof can damage the tent components.
Your Extended Limited Warranty does
not cover this damage.
