jbc CD-B User Manual

ø 1
ø 1,5
ø 3,5
A
A
B
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
Quick Tip Changer
Conical Chisel Conical
Bent
Bevel
Special
Models
Compatible Cartridges
The CD-B stations work with C245 cartridges and T245 handles.
Find the model that best suits your soldering needs in www.jbctools.com
Save time and change cartridges safely without switching the station off.
1. Removing 2. Inserting 3. Fixing
Place the handpiece in the
extractor and pull to remove
the cartridge.
Place the handpiece on top
of the new cartridge and
press down slightly.
Use the holes for fixing the
cartridge* as follows:
A. For straight C210.
B. For curved C210.
C. For C245.
*Important: It is essential to insert the cartridges as far as the mark for a proper connection.
B
C
A
Mark
www.jbctools.com
7
