jbc HA Series User Manual

Cartridge Stand for Robot ..................... 1 unit
Screw ........................................................... 2 unit
DIN 912 M6x20
Ref. 0842925
Washer ........................................................ 2 unit
DIN 125 Ø6.4 mm INOX
Ref. 0919480
Manual .................................................................................................................................................................. 1 unit
Ref. 0027877
Either Ref. CS2R245-B or Ref. CS2R470-B is included in CSR box:
Upper Center Jig ...................................... 1 unit
Ref. 0023652 for CS2R245-B
Ref. 0023625 for CS2R470-B
Lower Center Jig ...................................... 1 unit
Ref. 0023626 for CS2R245-B
Ref. 0023648 for CS2R470-B
www.jbctools.com
5
