JBL 515 XT - EON515 XT Specifications; System Specification; Amplification; Speaker Specification

11
(21;76SHFL¿FDWLRQV
System Type:
Self powered 15"WZRZD\EDVVUHÀH[
Maximum SPL Output: 132 dB
)UHTXHQF\5DQJHG% 39 Hz -20 kHz
)UHTXHQF\5HVSRQVHG% 42 Hz - 18 kHz
Input Connectors:
2 x 1/4" TRS phone jacks balanced/unbalanced 1 x XLR / 1/4" TRS combo jack with XLR loop through
Input Impedance: 14k ohms
Signal Indicators: Limit: Red LED indicates limiter active condition
Signal: Green LED indicates signal present
Mic: Indicates the MIC/LINE switch is in the “MIC” position
EQ:
Individual Bass and Treble controls, center detent, 6 dB cut and boost
%DVVG%+]WXUQRYHUIUHTXHQF\
7UHEOHG%N+]WXUQRYHUIUHTXHQF\
Mic Input Gain: ,Q¿QLW\WRG%X
Line Input Gain: ,Q¿QLW\WRG%XG%XPD[LPXPLQSXWOHYHO
Limiter: Yes
$PSOL¿HU'HVLJQ Crown
®
Class-D
System Power Rating: :DWWV
LF Driver:
1 x JBL 265F-1 380 mm (15"'LIIHUHQWLDO'ULYH
®
integrated woofer with dual 2" voice coils
HF Driver:
1 x JBL 2414H 37.5 mm (1.5"DQQXODUSRO\PHUGLDSKUDJPQHRG\PLXPFRPSUHVVLRQGULYHU
Coverage Pattern: +[9QRPLQDO
Crossover Frequency: 1.7 kHz
Material: Polypropylene, multi-purpose main & monitor
Suspension / Mounting: 36 mm pole socket with stabilizing screw, 5 x M10 suspension points
Handles: One left/right side, one on top, with rubber grip
Finish: Black Granite
Grille: Powder coated perforated steel with acoustically transparent cloth backing.
'LPHQVLRQV+[:['
673 mm x 406 mm x 368 mm (26.5" x 16" x 14.5"
Gross Weight: NJOE
Block Diagram
6\VWHP6SHFL¿FDWLRQ
$PSOL¿FDWLRQ
6SHDNHU6SHFL¿FDWLRQ
MIC
SIGNAL
LEVEL 2
LEVEL 1
INPUT 3
OUT
LOOP
MIX
INPUT 2
INPUT 1
BASS
HPF
LEVEL 3
LF
HF
SUM
LINE
MIC
LPF
TREBLE
EQ COMPRESSOR
OVERLOAD LED
EQ
Enclosure
