Specifications
Occasional refinements may
be made to existing products
without notice, but will
always meet or exceed origi-
nal specifications unless
otherwise stated.
*The maximum recommended
amplifier power rating will
ensure proper system head-
room to allow for occasional
peaks. We do not recommend
sustained operation at these
maximum power levels.
ARC10 ARC30
Frequency Response (–6dB): 75Hz – 20kHz 50Hz – 23kHz
Recommended Maximum
Power Handling*: 50 watts 125 watts
Sensitivity @ 1 watt/1 meter:
86dB 90dB
Nominal Impedance: 8 ohms 8 ohms
Crossover Frequency: 2200Hz 3700Hz
Woofer: 5-1/4" 6-1/2"
Midrange: N/A N/A
Tweeter: 2" paper cone 1" pure titanium
Dimensions (HxWxD): 11 x 6-1/2 x 7-1/4 inches 17-3/8 x 9-5/8 x 8-1/4 inches
280 x 165 x 184mm 441 x 245 x 210mm
Weight (each): 7 lbs/3.2 kg 16 lbs/7.3 kg
ARC1000 ARC Center
Frequency Response (–6dB): 36Hz – 23kHz 100Hz – 20kHz
Recommended Maximum
Power Handling*: 175 watts 70 watts
Sensitivity @ 1 watt/1 meter:
90dB 89dB
Nominal Impedance: 8 ohms 8 ohms
Crossover Frequency: 930Hz, 5600Hz 9000Hz
Woofer: 10" 2 x 4-1/2"
Midrange: 5" N/A
Tweeter: 1" titanium 2" paper cone
Dimensions (HxWxD): 39 x 12 x 11 inches 6 x 16 x 6-1/4 inches
991 x 305 x 209mm 152 x 406 x 159mm
Weight (each): 44 lbs/20 kg 9 lbs/4.1 kg
ARC Owners manual 7/22/98 2:32 PM Page 6
