two.Speaker Connections
Connection Tips
Speakers and electronics terminals have corresponding (+) and
(–) terminals. It is important to connect both speakers identi-
cally: (+) on the speaker to (+) on the amplifier and (–) on the
speaker to (–) on the amplifier. Wiring “out of phase” results in
thin sound, weak bass and a poor stereo image.
ARC10, ARC30
ARC1000
Standard Connection
ARC Center
ARC Owners manual 7/22/98 2:32 PM Page 3
