JBL BOOST TV - Spare Parts List

JBL BOOST TV SPARE PARTS LIST
Pos. No. Part Number Description
1
24104971101049 Front Housing BOOST TV
2
20140225025011 Driver 2.25" 4Ω 25W BOOST TV
3
24104971701049 Driver left bracket BOOST TV
5
24104971801049 Driver right bracket BOOST TV
7
993104860309 IR BOARD
14
24104971001049 Rear Housing BOOST TV
18
24104970901049 Port Tube Cover PC+ABS BOOST TV
22
24104971601049 Port Tube Left
24
24104971501049 Port Tube Right BOOST TV
38
24104970401049 Button Bracket BOOST TV
42
24104970301049 Foot Bracket BOOST TV
44
420202030109 RUBBER FOOT L183*W79*T2.0mm BOOST TV
45
420202020109 Silicon Button L110*W17.7*T1.58mm BOOST TV
31+32+33+34+37
331104970219 FABRIC GRILLE (1) BOOST TV BLK
40+41
331104970109 FABRIC GRILLE (2) BOOST TV WHT
423010050109 Bluetooth Antenna L=150MM BOOST TV
461122010649 2P Cable L=220MM W2.54 BOOST TV
461128000179 2P Cable L=80MM W2.54 BOOST TV
461631110069 FFC Cable L=110MM BOOST TV
461636000019 FFC Cable L=60MM BOOST TV
10
993104860109 Main BOARD
U14
232806050209 Bluetooth module BM880-CSR8687C BOOST TV
U11U12
403100150119 IC NJM4580M Dual Operational Amplifier DMP8 BOOST TV
U4
403200140109 IC ALPHA-SEMIC AS1117-3.3 SOT-223 BOOST TV
U13
403400420109 IC PIC32MX450F256L 100Pin TQFP BOOST TV
U18
403902570909 IC AS2930-3.3V SOT23-5 BOOST TV
U5
403902570929 IC AS2930-1.2V SOT23-5 BOOST TV
U7
403903600909 IC 74LVC2G04GW NXP Dual inverter 6 leads SOT363 BOOST TV
U10
403903600919 IC 74LVC1G3157GV NXP 2-channel analog SOT457 BOOST TV
U16
403903880209 IC 24C16-WMN6TP EEPROM 16Kbit Serial I2C SOP-8 BOOST TV
U17
403903010709 IC KH25L1606E 16M FLASH SOP8L BOOST TV
U9
403904490109 IC CS48L11 DSP BOOST TV
U8
403904500109 IC CS42528 192KHZ 8CH S/PDIF D/A BOOST TV
U3
403904560109 IC TPA3118D2 HTSSOP32PIN BOOST TV
U2
403905010109 IC MP2314 TSOT-23-8PIN BOOST TV
D1D3
405100020109 Diode BAT54C SOT-23 30V/200MA BOOST TV
D2
405100030109 Diode 1N4148 BOOST TV
Q3
406000370109 Transistor S8050LT1 SOT-23 BOOST TV
Q2
406000550109 Transistor 8550Y 800MA SOT-23 BOOST TV
Q4Q5Q6Q7
406000610109 Transistor NPN 2SC2712 TO236MOD BOOST TV
U6
406100680109 MOS PMOS P5102FMA SOT-23 UNIKC BOOST TV
L7
407000140509 Chip inductor 10UH 5A MCW-0630-100-N1 BOOST TV
L2L3L4L5
407000140909 Chip inductor 10uH 3A CKCBA74-10uH/M-V BOOST TV
L25
407001380409 Chip inductor 1.5uH 0603 BLM18HE152 BOOST TV
CN4
416010120219 FPC Jack 10PIN*1 P=0.5MM BOOST TV
CN12
416010230209 FPC Jack 18PIN*1 P=0.5MM H2mm BOOST TV
ANT1
416300180109 Transition Jack MINI BOOST TV
