JBL GX-A3001 Service Manual

Pos Part no. Part name Qty Unit Pos
10 AGXA602M0003 HARMAN,GX-A602,量产, 1 1
10 88AM03200519 GX-A602,功放板,DIP加工测试,量产, 1 1
10 88AM03100519 GX-A602,功放板,AI委外加工,量产, 1 1
10 88AM03000519 GX-A602,功放板,SMD外发,量产, 1 1
10 010103000024
▲
SMD,100KΩ,1/10W-0603,±1%,无 3 1 R61P, R83P, R154P
20 020113000008 SMD 101/50V 0603 NPO ±5% 8 1
C300, C301, C131, C132, C231,
C232, C302,C303
90 030123000121
DIP,2.5mH,ф0.7*8P*10.5Ts,JD2010 脚距18mm
镀锡
1 1 L6
100 040103000046 DIP 1N5404 DO-201AD 3A 400V 52mm 1 1 D15
110 050103000119 DIP,2SB688,TO-3P,SUNTECH,≥8A 80W PNP O 档, 2 1 Q112, Q212
120 130213000063 DIP Pitch 2.0MM 9PIN 直插 1 1 CN1B
130 050203000151 DIP,2SD718,TO-3P,SUNTECH,≥8A 80W NPN O 档, 2 1 Q111, Q211
140 040403000007
DIP F16A20CT 16A 200V 共阳 TO-220 Common：A
品牌：HS
1 1 D32
150 040503000016
DIP F16C20CT 16A 200V 共阴 TO-220 Common：C
品牌：HS
1 1 D31
160 050403000054 DIP,STP80N70F4,TO-220,ST,85A 68V N-CHANNEL, 2 1 Q22, Q26
170 050703000013 PC817 DIP4封装 1 1 U1P
180 120903000020 JSZ3A-63 黑色 上折脚 镀镍 十字头螺丝 3PIN 1 1 CN3
190 120903000025 JSZ4A-63 黑色 上折脚 镀镍 十字头螺丝 4PIN 1 1 JK1
200 020513000216
DIP 3300uF/25V ±20% 16*26 105
℃
高频低阻
2000H寿命 金黄色
1 1 C110
210 020513000185
DIP 2200uF/35V ±20% 16*26 105
℃
脚距7.5
高频低阻 2000H 金黄
2 1 C145,C146
220 GD0301000160 电解板,22*23*1.5MM,素材, 2 1
10 HDA030320007 1220*1220*1.5MM 1 1250
230 LS0101000040 PM3*10 黑锌加硬 2 1
240 LS0101000066 PM3*4\镀黑锌\加硬\耐落. 2 1
250 LS0101000088 圆头,3*8MM,无,镀黑锌,不加硬 4 1
260 200403000187 ,Φ31 5.5:10.5 0.7*4*5.5TS:0.8*2*10.5TS, 1 1 T1
270 170103000889
1015#18AWG
红白并线,2PIN,L=65mm,两端剥皮上锡4mm,
1 1 J70
280 JD0201000038 1孔 18*13*0.1MM 4 1
290 LS0101000086 圆头,3*6MM,无,镀黑锌,不需加硬 6 1
300 080513000014
DIP,PTC,300~500Ω,P=5.0,R80
℃
＞5KΩ 2 1 R3A,R3B
310 LP0902000008 ES 601B 硅胶 中性 300ml/瓶 2 150
320 JD0201000090 φ6*φ3.0*0.6mm 单面备3mm胶 4 1
330 JD0201000040 22*18*0.1MM 4 1
340 SR0101000053 铝型材,118*26*4, 1 1
10 HDA040820003 ,1600*26*4, 1 13
350 SR0101000054 铝型材,118*26*4, 1 1
10 HDA040820003 ,1600*26*4, 1 13
360 JD0101000022 φ5.6*φ3*1.3MM 电黑 2 1
20 88FA03200296 GX-A602,前级板,DIP加工测试,量产, 1 1
10 88FA03100296 GX-A602,前级板,AI委外加工,量产, 1 1
10 88FA03000296 GX-A602,前级板,SMD外发,量产, 1 1
10 010103000396 ▲SMD,0Ω,1/8W-0805,±5%,无 2 1 J3,J26
20 010103000551 SMD 0Ω 1/4W ±5% 1206 1 1 J4
30 010103000031 SMD 1.1KΩ 1/10W ±1% 0603 2 1 R7A,R7D
40 020113000008 SMD 101/50V 0603 NPO ±5% 6 1 C7A, C7B, C8A, C8B, C25A, C25B
50 020123000007 SMD 104/50V 0603 X7R ±10% 6 1 C14A, C15H,C1S, C2S,C2,C3

JBL GX-A3001 Specifications

General

Amplifier class	-
Frequency range	10 - 320 Hz
Audio output channels	1.0 channels
Peak power per channel	415 W
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	- %
RMS power output per channel (2 Ohm)	300 W
RMS power output per channel (4 Ohm)	200 W
DC-in jack	Yes
Line inputs (RCA)	2
Speakers connectivity type	RCA
Product color	Black

Weight and Dimensions

Depth	52 mm
Width	206 mm
Height	291 mm
