JBL GX-A3001 Service Manual

Pos Part no. Part name Qty Unit Pos
10 AGXA602M0003 HARMAN,GX-A602,量产, 1 1
10 88AM03200519 GX-A602,功放板,DIP加工测试,量产, 1 1
10 88AM03100519 GX-A602,功放板,AI委外加工,量产, 1 1
10 88AM03000519 GX-A602,功放板,SMD外发,量产, 1 1
10 010103000024
▲
SMD,100KΩ,1/10W-0603,±1%,无 3 1 R61P, R83P, R154P
20 020113000008 SMD 101/50V 0603 NPO ±5% 8 1
C300, C301, C131, C132, C231,
C232, C302,C303
70 010103000022 SMD 10KΩ 1/10W ±1% 0603 7 1
R5, R24A, R24B, R25A,
R25B,R27B,R26B
80 020113000005 SMD 10pF/50V 0603 NPO ±5% 2 1 C6A, C6B
90 020133000032 SMD,106/25V,0805,X5R,±10%,TDK 6 1 C2H, C5H, C3H, C4H, C6H, C7H
100 020123000067 SMD 183/50V 0603 X7R ±10% 2 1 C23A,C23B
110 010103000017 SMD 1KΩ 1/10W ±1% 0603 7 1
R20A, R20B, R28A,
R28B,R1,R16A, R16B
120 040103000020 SMD,LL4148,DO-213AA,ST, 1 1 D1
130 010103000121 SMD 220Ω 1/10W ±1% 0603 6 1
R14A, R14B, R15A, R15B,
R18A,R18B
140 010103000128 SMD 22KΩ 1/10W ±1% 0603 6 1 R1A, R1B, R19A, R19B, R8H, R9H
150 010103000231 SMD 39KΩ 1/10W ±1% 0603 2 1 R23A, R23B
160 010103000254 SMD 43KΩ 1/10W ±1% 0603 6 1
R21A, R21B, R22A,
R22B,R29A,R29B
170 010103000265 SMD 4.7KΩ 1/10W ±1% 0603 10 1
R2A, R3A, R3B, R4, R4A,R4B,
R5A, R5B, R27A,R2B
180 010103000003 SMD,2.2K,1W-2512,±5%, 2 1 R2H, R6H
190 020123000087 SMD 473/50V 0603 X7R ±10% 2 1 C11A,C11B
200 010103000268 SMD 47KΩ 1/10W ±1% 0603 4 1 R8, R9, R10, R11
210 010103000307 SMD 5.6KΩ 1/10W ±1% 0603 2 1 R6A, R6B
220 010103000523 SMD 5.6KΩ 1/8W ±1% 0805 2 1 R4H, R7H
230 010103000360 SMD 75KΩ 1/10W ±1% 0603 4 1 R10A,R10B,R12A,R12B
240 010103000311 SMD 56KΩ 1/10W ±1% 0603 2 1 R1S, R2S
250 020123000053 SMD 823/50V 0603 X7R ±10% 4 1 C34A,C34B, C35A, C35B
260 060103000062 SMD BA4560F SOP-8 ROHM 6 1 U1, U2,U3, U4, U5, U6
270 010103000278 SMD 4.99K 1/10W ±1% 0603 1 1 R6
280 010103000008 SMD 0Ω 1/10W ±1% 0603 1 1 J1
290 020113000053
SMD 471/50V 0603 NPO ±5% 2 1 C24A,C24B
300 010103000452 SMD 22KΩ 1/8W ±1% 0805 2 1 R3H, R5H
20 020513000044
DIP 10uF/16V ±20% 5*7 105
℃
脚距5MM 编带式 8 1
C3A, C3B, C4A, C4B, C5A, C5B,
C9A, C9B
30 170903000029 DIP φ0.6*10MM 编带式 6 1 J5,J7, J8, J12, J13,J20
40 170903000062 DIP φ0.6*12.5MM 编带式 8 1
J14, J15, J16,J17, J18, J19, J21,
J22
50 010203000052 DIP 1/8W 220Ω ±5% 编带式 2 1 R13A, R13B
70 170903000056 DIP φ0.6*7.5MM 编带式 6 1 J2, J6, J9, J10, J11,J23
80 020713000029 DIP M/C823/100V ±5% (小型化)绿色 编带式 2 1 C36A,C36B
90 010203000127 DIP 1/8W 82KΩ ±5% 编带式 2 1 R17A, R17B
100 020713000020 DIP 333/100V ±5% 编带式 脚距5mm 4 1 C11C, C11D, C23C, C23D
110 020523000010
DIP,100uF/25V,6.3*11,无极性 ,±20%,85
℃
无极性脚
距5MM编带式
2 1 C2A,C2B
120 23FA03000245
GX-A602,单层,60*156*1.6mm,FR-1,T1-03,材质FR-1
94V0-L 单面 1安士
1 1
130 170903000039 DIP φ0.6*17MM 编带式 1 1 J25
20 010703000103 DIP,B20K 双联,散装,±10%, H=11.3 L=7 1 1 VR2
30 120203000057 AV2-8.4-13AN(WR) 2孔上白下红 4个引脚 1 1 RCA1

JBL GX-A3001 Specifications

General

Amplifier class	-
Frequency range	10 - 320 Hz
Audio output channels	1.0 channels
Peak power per channel	415 W
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	- %
RMS power output per channel (2 Ohm)	300 W
RMS power output per channel (4 Ohm)	200 W
DC-in jack	Yes
Line inputs (RCA)	2
Speakers connectivity type	RCA
Product color	Black

Weight and Dimensions

Depth	52 mm
Width	206 mm
Height	291 mm
