JBL GX-A3001 Service Manual

Pos Part no. Part name Qty Unit Pos
10 AGXA602M0003 HARMAN,GX-A602,量产, 1 1
10 88AM03200519 GX-A602,功放板,DIP加工测试,量产, 1 1
10 88AM03100519 GX-A602,功放板,AI委外加工,量产, 1 1
10 88AM03000519 GX-A602,功放板,SMD外发,量产, 1 1
10 010103000024
▲
SMD,100KΩ,1/10W-0603,±1%,无 3 1 R61P, R83P, R154P
20 020113000008 SMD 101/50V 0603 NPO ±5% 8 1
C300, C301, C131, C132, C231,
C232, C302,C303
40 130223000018 DIP Pitch 2.54MM 4PIN 弯90度 1 1 CON1
50 040903000007 DIP φ3mm 红色发红光 高亮圆形 2P 1 1 LED1
60 040903000022 DIP φ3mm 绿色 圆形式普亮 两引脚 1 1 LED2
70 110103000017 DIP,SHC-22P-09,2P2T 柄长=6MM, 1 1 SW3
80 110103000077 DIP,14*6.5*8.5H,2P3T ,柄长6MM 左三右一, 1 1 SW2
90 170103000892
2468#26,9PIN,2.0mm,L=60mm,一端2.0公端头,另
一端2.0插针 同向, 紅白排线,
1 1 CN1A
30 SR0201100074
铝合金,193.9*206*50.3MM
,表面喷黑色织纹漆,无丝印,
1 1
10 SR0201000074 铝合金,193.9*206*50.3, 1 1
10 HDA060120001
▲
,ADC-12,铝合金锭 900 1
20 VSA000000915 ,黑色织纹烤漆,CA-6551/CH-KQ9854/F-2476 0,04 1
40 ZL0101000184
黄铜,H4.75*25.2
一端攻内牙M3*6,一端攻外牙M3*4,
2 1
50 LS0101000086 圆头,3*6MM,无,镀黑锌,不需加硬 2 1
60 LS0201000066 圆头割尾自攻牙 PT3*8MM 加硬 镀黑锌 3 1
70 MP0101000046
ABS,20.1*16.1*4.2MM, 黑色
LOGO烫金(银色）,无丝印,
1 1
10 MP0101000045 ABS,20.1*16.1*4.2, 1 1
10 PTABS2000012 ABS-757本色 2,45 1
80 MK0201200360
冷轧板,154.5*11*33.6MM,表面烤黑色平光漆 ,丝
印PMS Cool Grey 4C,丝印,
1 1
10 MK0201000360 冷轧板,154.5*11*33.6, 1 1
10 HDC010220001 ,175*0.8, 60 1
20 VSA000000569 ★黑平光,油漆,CH-KQ9711/F-2417/CA-2865/F-2737 0,005 1
90 HG0201200197
冷轧板,149.9*11*33.6MM,烤黑色平光漆,丝印PM
S Cool Grey 4C,丝印,
1 1
10 HG0201000197 冷轧板,149.9*11*33.6, 1 1
10 HDC010220001 ,175*0.8, 61 1
20 VSA000000569 ★黑平光,油漆,CH-KQ9711/F-2417/CA-2865/F-2737 0,008 1
100 GD0601300022
PC,121.7*122.2*9MM,
啤透明黑
丝印''GX''颜色PMS172 其他丝印灰色
1 1
10 GD0601000022 PC,121.7*122.2*9, 1 1
10 PTPC02000013
▲
PC-1225Y,透明/素材, 60 1
120 LS0101000088 圆头,3*8MM,无,镀黑锌,不加硬 6 1
130 JD0401000077 8*8*5mm 单面备胶 黑色 2 1
140 JD0101000387 ,红色快巴纸120*10*0.4单面背胶, 1 1
30 BZ0102000166 260*270*0.5MM 打双孔, 1 1
40 LS0201000083 圆头自攻牙尖尾加硬PA4*20MM (镀黑锌) 4 1
50 XG0201100182
冷轧板,180.85*192.8*1.6MM
T=0.8,表面烤黑色平光漆 丝印颜色PANTONE
427C,丝印,灰色,
1 1
10 XG0201000182 冷轧板,180.85*192.8*1.6, 1 6
10 HDA010220033 ,200*1220*0.8, 1 6

JBL GX-A3001 Specifications

General

Amplifier class	-
Frequency range	10 - 320 Hz
Audio output channels	1.0 channels
Peak power per channel	415 W
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	- %
RMS power output per channel (2 Ohm)	300 W
RMS power output per channel (4 Ohm)	200 W
DC-in jack	Yes
Line inputs (RCA)	2
Speakers connectivity type	RCA
Product color	Black

Weight and Dimensions

Depth	52 mm
Width	206 mm
Height	291 mm
