JBL MA6004 - SPECIFICATIONS; MA6004 Specifications; MA6002 Specifications

MA6004
•
60W RMS x 4 channels at 4 ohms and ≤1% THD + N
•Signal-to-noise ratio: 80dBA (reference 1W into 4 ohms)
•80W RMS x 4 channels at 2 ohms, 14.4V supply and ≤1% THD + N
•160W RMS x 2 channels at 4 ohms, 14.4V supply and ≤1% THD + N
•Dynamic power: 145W at 2 ohms
•Effective damping factor: 6.395 at 4 ohms
•Frequency response: 10Hz – 27kHz (–3dB)
•Maximum input signal: 6V
•Maximum sensitivity: 100mV
•Output regulation: –0.03dB at 4 ohms
•Dimensions (L x W x H): 13-1/4" x 10-1/4" x 2-3/16"
(337mm x 261mm x 56mm)
•Fuses: 25A x 2
MA6002
•60W RMS x 2 channels at 4 ohms and ≤1% THD + N
•Signal-to-noise ratio: 84dBA (reference 1W into 4 ohms)
•80W RMS x 2 channels at 2 ohms, 14.4V supply and ≤1% THD + N
•160W RMS x 1 channel at 4 ohms, 14.4V supply and ≤1% THD + N
•Dynamic power: 160W at 2 ohms
•Effective damping factor: 6.395 at 4 ohms
•Frequency response: 10Hz – 27kHz (–3dB)
•Maximum input signal: 6V
•Maximum sensitivity: 100mV
•Output regulation: –0.03dB at 4 ohms
•Dimensions (L x W x H): 9" x 10-1/4" x 2-3/16"
(229mm x 261mm x 56mm)
•Fuses: 25A x 1
SPECIFICA
TIONS
A valid serial number is required for warranty coverage.
Features, specifications and appearance are subject to change without notice.
JBL CAR AUDIO
CAR AMPLIFIERS
