JBL MA9100HP - Rear Panel

©2024 Harman International | Features, Specications, and Appearance subject to change without notice.
Pg 3 of 9
EN
Rear Panel
(ASSIGNABLE)
ONOFF
(eARC)
❽ ❾❺❶
❷ ❸ ❹ ❻ ❼ ❿
12
11
* MA7100HP shown
1. USB Socket
2. Ethernet Socket
3. Phono Input and Ground
4. Analog Inputs
5. Digital Inputs
6. Zone 2 "PARTY" Output
7. Subwoofer Outputs
8. HDMI Outputs
9. HDMI Inputs
10. Speaker Level Output Connectors
11. Power Switch
12. Power Input
