JBL Project K2 S9800 - Chapter 12: Specifications; Technical Specifications

29
Power Handling:
Frequency Response:
Low Frequency Extension:
Sensitivity:
Nominal Impedance:
Crossover Frequency:
Low Frequency Driver:
High Frequency Driver:
Ultra-High Frequency Driver
Dimensions:
Weight:
400W (RMS)
45Hz - 50kHz
35Hz (-10dB)
94 dB (2.83V/1m)
8 ohms
800Hz, 10kHz
380mm (15”) Pulp-Cone Woofer
(1500AL)
75mm (3”) Pure Beryllium
Compression Driver (435Be) +
38mm (1.5”) - throat Bi-radial Horn
25mm (1”) Pure Beryllium
Compression Driver (045Be) +
8.9mm (0.35”) - throat Bi-radial Horn
508mm (w) x 1,295mm (h) x 375mm (d)
90kg (198.4 lbs) per unit
CHAPTER 12
Project K2 S9800 Specifications
Project K2 S9800
