EN-40
Specifications
Stereo line inputs
Maximum input
4.5V rms
Nominal sensitivity
1V, 2V, 4V (user adjustable)
Input impedance
47kΩ
Signal/noise ratio (A-wtd ref 100W)
normal/stereo direct
100dB/110dB
Frequency response
20Hz—20kHz ± 0.1dB
Preamplifier outputs
Nominal output level (single-ended/balanced)
1V RMS/2V RMS (max. 5V RMS/10 V RMS)
Output impedance
560Ω
THD+N (20Hz—20kHz)
–100dB
Headphone output
Maximum output level into 32Ω
5Vrms
Output impedance
<100Ω
General
Mains voltage
110–120V or 220–240V, 50 –60Hz
Power consumption (maximum)
50W (Thermal dissipation approx. 170 BTU/hour)
Power consumption (idle, typical)
40W (Thermal dissipation approx. 170 BTU/hour)
Power consumption (standby)
<0.5W
Dimensions W x D
(including speaker terminals) x H (including feet)
433 x 425 x 171mm
Weight (net)
10.6kg
Weight (packed)
13.9kg
Supplied accessories
AC cord
Remote control with 2 x AAA batteries
Manual
DAB/FM antenna
3 x WiFi/Bluetooth antennas
Calibration microphone
USB cable
E&OE
NOTE: All specification values are typical unless otherwise stated.
SDP-55
Continual improvement policy: JBL Synthesis has a
policy of continual improvement for its products. This
means that designs and specifications are subject to
change without notice.
SDP-35
Continuous power output, per channel, 8Ω/4Ω
2 channels driven, 20Hz - 20kHz, <0.02% THD
120W/200W
2 channels driven, 1kHz, 0.2% THD
140W/220W
7 channels driven, 1kHz, 0.2% THD
100W/180W
Residual noise & hum (A-wtd)
<0.15mV
Stereo line inputs
Maximum input
4.5V rms
Nominal sensitivity
1V, 2V, 4V (user adjustable)
Input impedance
47kΩ
Signal/noise ratio (A-wtd ref 100W) normal/stereo direct
100dB/110dB
Frequency response
20Hz—20kHz ± 0.1dB
Preamplifier outputs
Nominal output level
1V RMS (max. 5V RMS)
Output impedance
560Ω
THD+N (20Hz—20kHz)
–100dB
Headphone output
Maximum output level into 32Ω
5Vrms
Output impedance
<100Ω
General
Mains voltage
110–120V or 220–240V, 50 –60Hz
Power consumption (maximum)
1.5kW (Thermal dissipation approx. 5200 BTU/hour)
Power consumption (idle, typical)
100W (Thermal dissipation approx. 340 BTU/hour)
Power consumption (standby)
<0.5W
Dimensions W x D
(including speaker terminals) x H (including feet)
433 x 425 x 171mm
Weight (net)
18.1kg
Weight (packed)
21.4kg
Supplied accessories
AC cord
Remote control with 2 x AAA batteries
Manual
DAB/FM antenna
3 x WiFi/Bluetooth antennas
Calibration microphone
USB cable
E&OE
NOTE: All specification values are typical unless otherwise stated.
