23
24
6. Bucket operation instruction
A
B
C
D
A. bucket frame safety lock hook
B. Bucket frame handle
C. Bucket lock
D. Bucket handle
step 1: First turn the safety lock
hook of bucket frame A clockwise.
1
2
step 2: Push the B bucket frame
handle forward.
B
1&2. Horn button: press the button to play the horn.
3. Forward/Reverse switch: press the button for controlling the Vehicle to move
forward, reverse.
4. Power switch: Turn on or turn off the power.
5. Foot pedal switch: Step on the foot pedal switch, the car will move forward;
Loosen the pedal, the car will stop.
4. Operation guide for Manual control (forward,
reverse ):
After the driver is seated, press the power switch. Put the
Forward/Backward switch into the position of “forward” (Press forward),
step on the foot switch the car will move forward , loosen the pedal the car
will stop. Put the Forward/Reverse switch into the position of “Reverse ”,
step on the foot switch the car will move reverse , loosen the pedal the car
will stop.
1 2
3
4
5
ON
OFF
5.Instructions of the recoverable fuse
Resettable fuse: when
the current exceeds a certain rating,
the recoverable fuse will automatically
cut off the power supply for 5-60
seconds, then the current will be
resupplied.
RISK OF FIRE. Do not bypass fuse. This may overload and damage the
electrical system. Replace only with original size and type.
!
WARNING
