Don’t remove the nut!Don’t remove the nut!
E
E
Firstly use a screwdriver to
unscrew the E (steering
wheel)cover in
counterclockwise, then
install 2 AA batteries as
shown, finally cover the
cover and tighten the
screws in clockwise.
Step 3: Install
steering wheel battery
+ -
+ -
+ -
+ -
1.All batteries should be inserted in the correct polarity.
2.Non-rechargeable battery cannot be recharged
3.Take out and properly deal with the dead battery. To avoid injury, please
keep kids away from the battery.
4.The direct contact between the positive and negative terminals may result
in fire or explosion. Avoid direct connect between the terminals.
5.Do not mix old and new batteries. Do not mix alkaline, standard(carbon-
zinc),or rechargeable(nickel-cadmium) batteries.
6.Only an adult who has read and understood the safety warnings can
replace the dry battery.
E
E
E
E
Step 4: Install steering wheel
1. Remove the screw from the E(steering wheel) firstly.
2. Place and fix E(steering wheel)on [5] steering yoke as shown in figure.
Then insert the screw back to the E(steering wheel).
[5]
C2 C2
C2
Rear
Note: Two A (M8 Spanner) wrenches are required use at same time
when removing and instaling the nut [4].
Install steering wheel
Connect EA(steering
wheel) with EB(steering
wheel support) together,
as shown in the figure.
CONFIGURATION A
E
EA
E
EB
To Next Page
