jcb 210X Service Manual

01 - Machine
09 - Description
15 - Service Point Locations
01 - 27 9813/9600-2 01 - 27
Service Points - Heating and Ventilation System
Figure 10.
F
E
D
A
C
B
A Cooling compartment B High pressure recharge point (air conditioning
only)
C Low pressure recharge point (air conditioning
only)
D Condenser radiator (air conditioning only)
E Fresh air filter F Recirculation filter
