01 - Machine
09 - Description
15 - Service Point Locations
01 - 26
9813/9600-2
01 - 26
Figure 9. Hydraulic compartment
B
G
F
E
D
C
A
H
A
Hydraulic pump compartment
B
Fuel lubricity filter (if installed)
C
Fuel pre-filter and water separator
D
Fuel line isolator valve
E
W
ater separator (if installed)
F
Fuel tank water drain of
f valve
G
Engine oil filter
H
Engine fuel filter
31
33
