About the Product
Operator Station
15 9831/3750-3 15
Operator Station
Component Locations
Figure 11.
B
R
D
F
E
J
K
L
S
Q
H
A
T
C
G
V
U
U
M
N
P
A Track controls Refer to: Track Controls
(Page 60).
B Display unit Refer to: Instrument Panel
(Page 64).
C Switch panel Refer to: General (Page 19). D Dozer control (option) Refer to: Dozer Blade
Controls (Page 93).
E Right joystick Refer to: Excavator End Controls
(Page 85).
F Dial control panel Refer to: General
(Page 19).
