jcb 3CXG - Main Component Locations

01 - Machine
09 - Description
12 - Main Component Locations
01 - 21 9813/4250-6 01 - 21
12 - Main Component Locations
Introduction .................................................... 01-21
Component Identification ............................... 01-22
Introduction
Figure 5.
F
D
C
A
H
B
E
G
A Dipper B Boom
C Stabilisers D ROPS (Roll-Over Protective Structure)/FOPS
(Falling Object Protective Structure) cab
E Hydraulic oil tank F Loader arm
G Fuel tank H Kingpost
