03 - Attachments, Couplings and Load Handling
00 - Attachments
00 - General
03 - 5 9813/4250-6 03 - 5
Excavator Arm Quickhitch (Hydraulic)
Figure 11.
Power Sideshift
Figure 12.
Knuckle (If Installed)
CAUTION Waxoyl contains turpentine substitute
which is flammable. Keep flames away when
applying Waxoyl. Waxoyl can take a few weeks
to dry completely. Keep flames away during the
drying period.
Do not weld near the affected area during the
drying period. Take the same precautions as for
oil to keep Waxoyl off your skin. Do not breathe
the fumes. Apply in a well-ventilated area.
Figure 13.
