jcb 3DX Super User Manual

15 - Engine
42 - Rocker and Fittings
00 - General
15 - 157 9823/0000-1 15 - 157
Component Identification
(For: JCB Tier 2/3 Mech Engine 4 Cyl)
Figure 200.
743830
4
7
4
5
4
4
4
4
4
1
6
2
3
2
2
2
2
2
2
1 Rocker shaft assembly 2 Rocker shaft fixing bolts (x7)
3 Rocker shaft - oil feed pedestal fixing bolt (x1) 4 Pedestals (x7)
5 Oil feed pedestal (x1) 6 Bridge pieces (x8)
7 Push rods (x8)
