jcb 4CX AEC - POLE MASTER PLUS - Earth Drill

Introduction
Main Component Locations
5 5
9831-0300-01
Earth Drill
P046740-04
Fig 4.
H
G
E
A
C
D
F
B
Component Key:
A Body
B Tail Hoses
C Auger
D Auger Teeth
E Pilot Bit
F Swivel Pin
G Gear Box
H Hydraulic Motor
