jcb 4CX AEC - POLE MASTER PLUS - Rotaclaw

Introduction
Main Component Locations
3 3
9831-0300-01
Rotaclaw
P046740-01
Fig 2.
H
D
E
B
A
G
F
C
Component Key:
A Tail Hoses
B Hydraulic Clamp
C Grab
D Side Cutters
E Access Covers
F Bucket
G Rotating Hanger
H Grab Pole Diameter Adjustors
