jcb 4CX Service Manual

iii
Section F Transmission
9803/3280
Section F
iii
Issue 2*
Contents Page No.
Rear Axle – PD70, SD80
Removal and Replacement 90 - 1
Brakes
Dismantling and Assembly 91 - 1
Hub and Driveshaft - SD80
Dismantling and Assembly 92 - 1
Hub and Driveshaft - PD70
Dismantling and Assembly 93 - 1
Drivehead
Dismantling and Assembly 94 - 1
Crownwheel and Pinion Meshing 94 - 8
Axles
Collapsible Spacer 95 - 1
Limited Slip Differential
Dismantling and Assembly 100 - 1
Synchro Shuttle Gearbox
Removal and Replacement 105 - 1
Dismantling 110 - 1
Inspection 111 - 1
Assembly 112 - 1
Clutch Dismantling and Assembly Procedures
Forward/Reverse Clutch 113 - 1
2/4 Wheel Drive Clutch (4WD Pressure On) 114 - 1
2/4 Wheel Drive Clutch (4WD Pressure Spring On) 115 - 1
2/4 Wheel Drive Clutch Pressure Testing 116 - 1
Piston Ring Seals - Fitting Procedure 117 - 1
Powershift Gearbox
Removal and Replacement 120 - 1
Dismantling 125 - 1
Inspection 126 - 1
Assembly 127 - 1
Clutch Dismantling and Assembly Procedures
Forward/Input and Reverser Clutch 130 - 1
Layshaft Clutch 131 - 1
Mainshaft Clutch 132 - 2
6 Speed Clutch 133 - 1
2/4 Wheel Drive Clutch 134 - 1
Piston Ring Seals - Fitting Procedure 140 - 1
Torque Converter
Removal and Replacement 150 - 1
