01 - Machine
09 - Description
12 - Main Component Locations
01 - 22 9813/7850-2 01 - 22
(For: JCB 30PLUS)
Figure 4.
A
B
C
D
E
F
G
A Dipper (part of the excavator arm) B Boom (part of the excavator arm)
C Cab (contains the operator station) D Upper structure
E Undercarriage F Dozer blade
G Bucket
