12 - Main Component Locations
Introduction
For: 8026 CTS [T3] ................... Page 01-21
For: JCB 30PLUS ..................... Page 01-22
(For: 8026 CTS [T3])
Figure 3.
A
B
C
D
E
F
G
A Dipper (part of the excavator arm) B Boom (part of the excavator arm)
C Cab (contains the operator station) D Upper structure
E Undercarriage F Dozer blade
G Bucket
