jcb G70RS User Manual

12 Please consult your manual for full information or consult your local dealer.
Item Function
G Silence Horn Turns off an alarm horn (if configured) and enters the alarm menu.
H Shortcut Menu Gives access to: Jump menu, mode selection, test and lamp test .
J Semi-Auto Mode The controller cannot automatically start, stop, connect or disconnect the generator.
The operator can start, stop, connect or disconnect the generator.
The controller automatically synchronises before closing a breaker, and
automatically de-loads before opening a breaker.
K Mains Symbol Green: The mains voltage and frequency are ok, and the controller can
synchronise and close the breaker.
Red: Mains failure.
L Close Breaker Press to close the breaker.
M Open Breaker Press to open the breaker.
N Breaker Symbols Green: Breaker is On.
Green flashing: Synchronising or de-loading.
Red: Breaker failure.
P Generator Green: The generator voltage and frequency are OK, and the controller can
synchronise and close the breaker.
Green flashing: The generator voltage and frequency are OK, but the Voltage
and Hertz OK timer is still running. The controller cannot close the breaker.
Red: The generator voltage is too low to measure.
Q Engine Green: There is running feedback.
Green flashing: The engine is getting ready.
Red: The engine is not running or there is no running feedback.
R Stop Stops the generator if semi-auto or manual is selected.
S Start Starts the generator if semi-auto or manual is selected.
T Load Symbol Off: Power management application.
Green: The supply voltage and frequency are OK.
Red: Supply voltage/frequency failure.
Control panel – DEIF AGC 150
