06 - Body and Framework
33 - Articulated Joint
00 - General
06 - 14 9813/7700-3 06 - 14
Figure 11.
A
E
B
C
G
J
K
L
M
N
W
D
F
H
Y
Z
R
T
V
P
Q
S
U
X
AB
AC
AD
AA
A Bolt B Washer
C Bearing plate D Support washer 1
E Disc spring 1 F Bearing cup 1
G Bearing cone 1 H Seal 1
J Seal 2 K Bearing cone 2
L Bearing cup 2 M Central joint
N Capscrew P Bolt
Q Bottom bearing pivot R Seal 3
S Bearing cone 3 T Bearing cup 3
U Support Washer 2 V Disc spring 2
W Bolt X Bearing cover
Y Support Washer 3 Z Bearing cup 4
AA Bearing cone 4 AB Seal 4
AC Drum frame AD Drum frame lug
