Pump Control
Display Monitor (continued)
Warning Display (Message Display)
Note 1: If several instructions are displayed they appear alternately every 5 seconds.
Note 2: When AUTO GLOW warm-up is finished, buzzer is sounded for 3 seconds.
START
Key SW ON
Key SW ON & Engine Running
! Overheat
! Electric system abnormality
! Refuel
! Refill coolant
! Engine emergency stop
Idling
Free swing
Engine warm up
! Battery charging Deficient
! Engine oil pressure down
! Air cleaner clogged
! Engine filter clogged
!Replenish battery fluid
Auto warm-up
One-touch digging force up
H: Heavy mode
S: Standard mode
L: Light mode
F: Fine mode
YES
NO
Message Display
Warning
! Engine emergency stop Engine emergency stop (emergency stop switch “ON”) is displayed.
! Refuel Fuel amount indicated if low. Check, and supply fuel.
! Refill coolant Coolant level is low. Check and supply cooling water.
! Replenish battery fluid Battery liquid level sensor is not fitted. Fault should not be displayed.
! Air cleaner clogged Air cleaner element is clogged. Wash or replace element.
! Engine oil pressure down Pressure of engine oil low. Check engine oil quantity, and replenish if low.
! Engine filter clogged Engine oil filter is clogged. Replace engine oil filter. (When replacing engine oil filter,
also replace engine oil).
! Over heat Engine coolant or hydraulic oil temperature is high. Turn engine to low idling, to lower the
water or oil temperature.
(Check radiator, and clean it.)
! Battery Charging Deficient Abnormal charging system is displayed. Check the electric circuit.
! Electric system abnormality Abnormal electric system (short and disconnection) is displayed. Check the electric
circuit.
