8 - 1
Section J
T
rack and Running Gear
9803/6400
Section J
8 - 1
Issue 2*
Drive Sprocket
W
ear Limits
Item
Dimension
Machine
Standard Size
Service Limit
Action
mm
in
mm
in
Width
a
JS200
66
2.59
60
2.59
Renew
JS240
Diameter
b
JS200
582.5
22.93
576.5
22.69
Renew
JS240
Diameter
c
JS200
659
25.9
65.3
25.7
Renew
JS240
Diameter
d
JS200
644.6
25.37
Renew
JS240
Centres
e
JS200
190
7.4
Renew
JS240
*
512
514
