Message Display Meaning
ALT VOLTS Alternator output voltage
BAT VOLTS Battery voltage
CALIBRATE Calibrate throttle control (set up engine speeds)
CLOCK To set time
DATE To set date
DEG C Degrees centigrade
ENGINE HOUR Total engine running hours
ENGLISH Language name
FUEL LEVEL Fuel tank level (Ohms)
HRDWARE VER Hardware (controller) version
HYD OIL TMP Hydraulic oil temperature (ºC)
HYD TEMP Hydraulic oil temperature too high
ID Identification
LANGUAGE Language name that the system is displaying
LIMP MODE Emergency mode if controller fails
LOW BAT Low battery voltage
LOW FUEL Low fuel level in fuel tank
LOW IDLE Engine at low idle
NO THROTTLE No throttle control
OHMS Resistance in ohms
OIL PRESS Low oil pressure
OVER-RIDE Solenoid over-ride system for test
PERC Percent
PILOT SWITCH Pilot pressure switch
PREHEAT Engine preheat on (Glow plugs)
RES FUEL Reserve level in fuel tank
SENSOR VOLT Sensor voltage
SERIAL NO Machine serial number
SERVICE OFF Switch off service required warning lamp
SFTWARE VER Software version
SWING BRAKE Swing brake on
SWING LOCK Swing lock on
THROTTL PWM Throttle system Pulse Width Modulation value
THRTTLE POT Throttle volume potentiometer voltage (from throttle dial in cab)
VOLTS Voltage
WATER TEMP Engine water temperature (ºC)
TVOL MIN Throttle volume minimum
TVOL MAX Throttle volume maximum
TSENS Throttle sensor
MODE Swing mode
MODE Offset mode
VER Software / Hardware version
SWING OFF Swing mode off
SWING ON Swing mode on
ERROR Error
ELECT FAULT Electrical fault open circuit/short circuit/no volts
Monitor Panel (contd)
