Operation
Operating Levers/Pedals
30 9831/3200-3 30
Figure 18.
A Emergency stop switch B Joystick (forwards/backwards)
C Turn left switch D Turn right switch
E Safety trigger/enable switch F Raise/lower mode
G Drive mode H Display
J Horn button K Speed button
The platform control lever is installed on a portable bracket that can be moved around the platform. The platform
controller can be fitted to the ground controller to suit the operation.
