jcb S1930E User Manual

Technical Data
Static Dimensions
86 9831/3200-3 86
(For: S3246E)
Table 20.
Description Dimension
Maximum platform height 10m (32' 9")
Maximum working height 12m (39' 4")
Platform size (L x W x H) 2.25m x 1.15m x 1.1m
Ground clearance 0.1m
Wheelbase 1.85m
Extension outreach 0.9m
Overall length (stowed) 2.39m
Overall width (stowed) 1.15m
Overall height (stowed, guardrail folded) 1.86m (6' 1")
Overall height (stowed, guardrail unfolded) 2.48m (8' 1")
(For: S4046E)
Table 21.
Description Dimension
Maximum platform height 11.9m (39' 0")
Maximum working height 13.9m (45' 7")
Platform size (L x W x H) 2.25m x 1.15m x 1.1m
Ground clearance 0.1m
Wheelbase 1.85m
Extension outreach 0.9m
Overall length (stowed) 2.39m
Overall width (stowed) 1.15m
Overall height (stowed, guardrail folded) 1.98m (6' 5")
Overall height (stowed, guardrail unfolded) 2.60m (8' 6")
(For: S4550E)
Table 22.
Description Dimension
Maximum platform height 13.8m (45' 3")
Maximum working height 15.8m (51' 10")
Platform size (L x W x H) 2.64m x 0.81m x 1.1m
Ground clearance 0.1m
Wheelbase 2.22m
Extension outreach 0.9m
Overall length (stowed) 2.76m
Overall width (stowed) 1.25m
Overall height (stowed, guardrail folded) 2.20m (7' 2")
Overall height (stowed, guardrail unfolded) 2.60m (8' 6")

jcb S1930E Specifications

General

Power Source	Electric
Stowed Height	2.03m
Drive Speed - Elevated	0.8 km/h
Gradeability	25%
Tyre Type	Non-marking
Ground Clearance	0.1m
