JCM EBA-30-SD3 - Disassembling D-Guide Unit

4 - 10
CHAPTER 4 Disassembly Instruction
6. Disassembling D-Guide Unit
6-1 Remove the ratchet from D-guide unit.
6-2 Remove the centering guides from D-guide
unit.
6-3 Remove screws and gears from D-guide unit.
